DSTIKE Deauther Watch X — ESP8266 Watch

Classic ESP8266 Wi-Fi Development Watch

The DSTIKE Deauther Watch X is a compact, open-source ESP8266 development device designed for makers, wireless technology education, firmware development, and authorized 2.4 GHz network assessment.

All versions combine a customized 4MB ESP-07 module, 1.3-inch OLED display, three-way navigation switch, rechargeable battery, programmable RGB LED, clock functionality, soft silicone strap, and protective transparent enclosure in a wearable format.

This listing includes both the classic color Watch X and the upgraded black Watch X II. Please review the version comparison before ordering.

The Watch X supports 2.4 GHz Wi-Fi only. It does not support 5 GHz Wi-Fi.

What Is It?

The Deauther Watch X is an ESP8266 development board integrated into a wearable enclosure.

It arrives with compatible ESP8266 Deauther firmware installed, providing an interface for wireless network scanning, signal observation, packet monitoring, clock display, and controlled protocol assessment on authorized 2.4 GHz networks.

The ESP8266 platform is also programmable through the Arduino IDE. Developers can replace the supplied firmware and use the display, buttons, RGB LED, buzzer, RTC hardware, and connection pads for custom wearable or IoT projects.

Why Did We Make It?

Most ESP8266 development boards require a separate display, battery, buttons, charging circuit, and enclosure before they can be used as a portable device.

The Watch X integrates these components into one compact platform:

• Customized 4MB ESP-07 module

• 1.3-inch OLED display

• Three-way navigation control

• Rechargeable battery and charging circuit

• Programmable RGB LED

• Buzzer on classic Watch X versions

• RTC hardware for timekeeping

• Sensor and expansion pads

• Transparent protective enclosure

• Soft silicone watch strap

This provides an accessible platform for ESP8266 learning, portable development, and wireless technology education.

Choose Your Version

Classic Watch X — Color Versions

Available colors:

• Green

• Red

• White

• Yellow

• Purple

The classic Watch X includes:

• 500mAh rechargeable battery

• Micro USB charging and firmware connection

• Built-in buzzer

• Approximately 5–6 hours of typical active operation

• Internal antenna configuration

• Transparent enclosure and silicone strap

Watch X II — Black Version

The black BLACK (X II) option is the upgraded version.

It includes:

• Larger 700mAh rechargeable battery

• USB-C charging and firmware connection

• Socket hex screws

• Updated RGB LED hardware

• Improved external power control

• Approximately 7–8 hours of typical active operation

• Internal antenna configuration

• Transparent enclosure and silicone strap

Actual operating time depends on battery condition, display activity, Wi-Fi use, RGB brightness, firmware settings, and environmental conditions.

Watch X and Watch X II Comparison

Expansion Board Options

Each color option is also available with an antenna expansion board.

Standard Watch

Includes the selected Watch X or Watch X II with its standard internal antenna configuration.

Watch with Expansion Board

Includes the selected watch plus a compatible antenna expansion board for external antenna development and experimentation.

An external antenna is not included unless it is specifically shown or stated in the selected product option.

Wireless performance depends on the antenna, channel, surrounding environment, interference, device orientation, and local radio regulations.

What Makes It Special?

• Customized 4MB ESP-07: Provides more flash storage than standard 1MB ESP8266 configurations.

• Wearable Development Platform: Combines display, controls, battery, indicators, and enclosure in one compact device.

• 1.3-Inch OLED Display: Shows menus, network information, packet-monitoring data, clock information, and operating status.

• Three-Way Navigation Control: Scroll up, scroll down, and confirm selections with one compact switch.

• Programmable RGB LED: Provides status feedback and can be controlled through custom firmware.

• Built-In Buzzer: Available on classic Watch X versions for alerts, button feedback, and custom sound patterns.

• RTC Hardware: Maintains clock information when the main Wi-Fi controller is powered down.

• Expansion Pads: Allow compatible sensors and other modules to be connected for custom development.

• Optional Antenna Expansion: Provides additional flexibility for compatible external antenna projects.

• Open-Source Firmware: Compatible with the ESP8266 Deauther ecosystem and custom Arduino applications.

• Protective Construction: Double acrylic protection and a transparent enclosure help protect the PCB.

• Comfortable Strap: Includes a soft silicone strap for wearable use.

Key Features

• Customized ESP8266 ESP-07 module

• 4MB flash memory

• 2.4 GHz Wi-Fi support

• Wireless network scanning

• Signal and channel observation

• Packet and activity monitoring

• Controlled protocol testing on compatible networks

• 1.3-inch SH1106 OLED display

• Three-way navigation switch

• Programmable WS2812B RGB LED

• Built-in rechargeable battery

• RTC timekeeping hardware

• Charging-status indicator

• Sensor and expansion pads

• Optional antenna expansion board

• Transparent enclosure

• Soft silicone strap

• Preloaded ESP8266 Deauther firmware

• Arduino IDE compatibility

Firmware Functions

Depending on the installed firmware version, the Watch X may provide:

• 2.4 GHz wireless network scanning

• Signal-strength and channel information

• Packet and activity monitoring

• Controlled management-frame assessment

• Beacon and probe-frame demonstrations in authorized laboratory environments

• Clock and time display

• Programmable RGB and LED functions

• Web-based firmware configuration

• Custom SSID and device settings

All wireless assessment functions are intended exclusively for networks and equipment that you own or have explicit permission to test.

Hardware Connections

GPIO availability and buzzer hardware may vary between the classic Watch X and Watch X II production versions.

Technical Specifications

Power and Charging

Classic Watch X

• Battery capacity: 500mAh

• Connection: Micro USB

• Typical active runtime: approximately 5–6 hours

Black Watch X II

• Battery capacity: 700mAh

• Connection: USB-C

• Typical active runtime: approximately 7–8 hours

Charging-status indicator:

• Red: Charging

• Green: Fully charged

The charging circuit includes protection against short circuits, overcharging, over-discharging, and abnormal temperature conditions.

Press and hold the power control for approximately two seconds to turn the device on or off.

Do not charge the device unattended. Stop using it if the battery becomes swollen, damaged, unusually hot, or produces an unusual smell.

What’s in the Box?

Standard Watch Option

• 1 × Selected DSTIKE Deauther Watch X or Watch X II

• 1 × Built-in rechargeable battery

• 1 × Silicone watch strap

• 1 × Compatible USB data and charging cable

• 1 × Quick-start guide

The supplied cable will match the selected watch version:

• Micro USB for classic color Watch X

• USB-C for black Watch X II

Watch with Expansion Board

• 1 × Selected DSTIKE Deauther Watch X or Watch X II

• 1 × Antenna expansion board

• 1 × Built-in rechargeable battery

• 1 × Silicone watch strap

• 1 × Compatible USB data and charging cable

• 1 × Quick-start guide

Open-Source Development

The Watch X is compatible with the open-source ESP8266 Deauther project:

https://github.com/SpacehuhnTech/esp8266_deauther

Developers can also create custom Arduino applications such as:

• Wearable sensor displays

• Wi-Fi signal monitors

• Clock and timer projects

• Portable IoT controls

• LED notification devices

• Buzzer alerts

• Custom menu interfaces

• ESP8266 programming exercises

Documentation:

https://deauther.com/docs/category/usage

Important Wireless-Band Notice

The Watch X and Watch X II support 2.4 GHz Wi-Fi only.

They do not support:

• 5 GHz Wi-Fi

• Wi-Fi 6

• 5G cellular connectivity

• SIM cards or mobile data

For 5 GHz Wi-Fi support, choose the Deauther32 Watch MINI or Watch MAX.

Firmware and Network Compatibility

Available functions depend on the installed firmware version.

Controlled packet-testing functions may be affected by the selected Wi-Fi channel, network hardware, regional settings, and network security configuration. Networks using Protected Management Frames, including 802.11w/PMF, may limit or prevent certain assessment functions.

The device does not bypass PMF protection.

Responsible Use and Legal Notice

This device is intended for education, open-source development, wireless signal monitoring, network diagnostics, and authorized security testing only.

Use it exclusively on networks and equipment that you own or for which you have received explicit permission to test. Unauthorized disruption of wireless communications may be illegal and could cause service interruptions.

Regulations governing wireless testing, external antennas, and 2.4 GHz transmissions vary by country or region. The user is responsible for complying with all applicable local radio, privacy, and telecommunications regulations.

The ESP8266 and its original SDK were not designed as professional wireless-assessment equipment. The supplied firmware is experimental, features may change, and bugs may occur.
